Dataset Title:  TEMPESTS MD205 Waves - CINAR   RSS
Institution:  NERACOOS   (Dataset ID: CINAR_DSG_MD205_waves)
Range: longitude = -75.00555 to -75.00555°E, latitude = 38.26539 to 38.26539°N, depth = 0.0 to 0.0m, time = 2016-08-02T16:50:00Z to 2016-11-08T19:50:00Z
Information:  Summary ? | License ? | FGDC | ISO 19115 | Metadata | Background | Subset | Data Access Form

Graph Type:  ?
X Axis:
Y Axis:
-1 +1

Constraints ? Optional
Constraint #1 ?
Optional
Constraint #2 ?






Server-side Functions ?
 distinct() ?
? (" ")

Graph Settings
Color:
Y Axis Minimum:   Maximum:   Ascending:

(Please be patient. It may take a while to get the data.)

Optional:
Then set the File Type: (File Type information)
and
or view the URL:
(Documentation / Bypass this form ? )
    [The graph you specified. Please be patient.]



Things You Can Do With Your Graphs

Well, you can do anything you want with your graphs, of course. But some things you might not have considered are:

The Dataset Attribute Structure (.das) for this Dataset

Attributes {
 s {
  station {
    String cf_role "timeseries_id";
    String ioos_category "Identifier";
    String long_name "MD205";
    String name "MD205";
    String short_name "MD205";
    String standard_name "station_name";
  }
  time {
    Int32 _ChunkSizes 512;
    String _CoordinateAxisType "Time";
    Float64 actual_range 1.4701566e+9, 1.4786346e+9;
    String axis "T";
    String calendar "gregorian";
    String ioos_category "Time";
    String long_name "Time";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
  }
  mooring_site_desc {
    String ioos_category "Location";
    String long_name "Station Description";
  }
  index {
    Int32 _ChunkSizes 755;
    Int32 _FillValue -999;
    Int32 actual_range 0, 353;
    Float64 colorBarMaximum 1.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Unknown";
    Int32 is_dead 0;
    String long_name "microstrain matching index";
    String short_name "index";
    String units "1";
    Int32 valid_range 0, 2147483647;
  }
  significant_wave_height {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.0, 3.6038;
    String ancillary_variables "significant_wave_height_qc";
    Float64 colorBarMaximum 10.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Surface Waves";
    Int32 is_dead 0;
    String long_name "Significant Wave Height";
    String short_name "SWH3";
    String standard_name "sea_surface_wave_significant_height";
    String units "m";
    Float32 valid_range 0.0, 10.0;
  }
  significant_wave_height_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Significant Wave Height QC";
    String short_name "SWH3Q";
    String standard_name "sea_surface_wave_significant_height_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  maximum_wave_height {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.0, 5.7591;
    String ancillary_variables "maximum_wave_height_qc";
    Float64 colorBarMaximum 20.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Surface Waves";
    Int32 is_dead 0;
    String long_name "Maximum Wave Height 3";
    String short_name "MWH3";
    String standard_name "sea_surface_wave_maximum_height";
    String units "m";
    Float32 valid_range 0.0, 15.0;
  }
  maximum_wave_height_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Maximum Wave Height QC";
    String short_name "MWH3Q";
    String standard_name "sea_surface_wave_maximum_height_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  dominant_wave_period {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.0, 14.815;
    String ancillary_variables "dominant_wave_period_qc";
    Float64 colorBarMaximum 20.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Surface Waves";
    Int32 is_dead 0;
    String long_name "Dominant Wave Period";
    String short_name "DWP3";
    String standard_name "sea_surface_wave_dominant_period";
    String units "s";
    Float32 valid_range 0.0, 32.0;
  }
  dominant_wave_period_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Dominant Wave Period QC";
    String short_name "DWP3Q";
    String standard_name "sea_surface_wave_dominant_period_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  mean_wave_direction {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 76.43, 348.2;
    String ancillary_variables "mean_wave_direction_qc";
    Float64 colorBarMaximum 360.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Surface Waves";
    Int32 is_dead 0;
    String long_name "Mean Wave Direction)";
    String short_name "MWD";
    String standard_name "mean_wave_direction";
    String units "degrees";
    Float32 valid_range 0.0, 360.0;
  }
  mean_wave_direction_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Mean Wave Direction QC";
    String short_name "MWDQ";
    String standard_name "mean_wave_direction_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  r1 {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.0, 0.95;
    String ancillary_variables "r1_qc";
    Float64 colorBarMaximum 400.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Unknown";
    Int32 is_dead 0;
    String long_name "R1";
    String short_name "MWDS3";
    String standard_name "r1";
    String units "degrees";
    Float32 valid_range 0.0, 360.0;
  }
  r1_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "R1 QC";
    String short_name "R1Q";
    String standard_name "r1_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  principal_wave_direction {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.24, 359.26;
    String ancillary_variables "principal_wave_direction_qc";
    Float64 colorBarMaximum 360.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Surface Waves";
    Int32 is_dead 0;
    String long_name "Principal Wave Direction";
    String short_name "PWD";
    String standard_name "principal_wave_direction";
    String units "degrees";
    Float32 valid_range 0.0, 360.0;
  }
  principal_wave_direction_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_non_functional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Principal Wave Direction Qc";
    String short_name "PWDQ";
    String standard_name "principal_wave_direction_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  r2 {
    Int32 _ChunkSizes 755;
    Float32 _FillValue -999.0;
    Float32 actual_range 0.0, 0.94;
    String ancillary_variables "r2_qc";
    Float64 colorBarMaximum 400.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Unknown";
    Int32 is_dead 0;
    String long_name "R2";
    String short_name "PWDS3";
    String standard_name "r2";
    String units "degrees";
    Float32 valid_range 0.0, 360.0;
  }
  r2_qc {
    Int32 _ChunkSizes 2264;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_non_functional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "R2 QC";
    String short_name "R2Q";
    String standard_name "r2_qc";
    String units "1";
    Byte valid_range -127, 127;
  }
  offset_time {
    Int32 _ChunkSizes 453;
    Float64 _FillValue -999.0;
    Float64 actual_range -270.0, 30.0;
    Float64 colorBarMaximum 4000.0;
    Float64 colorBarMinimum -4000.0;
    String Comment "Add to time for actual sensor reading ";
    String coordinates "time lon lat depth";
    String ioos_category "Time";
    String long_name "Offset from regular time interval";
    String short_name "off_time";
    String standard_name "offset_time";
    String units "seconds";
    Float64 valid_range -3600.0, 3600.0;
  }
  time_created {
    Int32 _ChunkSizes 453;
    Float64 actual_range 1.470171234528697e+9, 1.4786362141052246e+9;
    Float64 colorBarMaximum 120000.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Time";
    String long_name "Time Record Created";
    String short_name "time_cr";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
    Float64 valid_range 0.0, 99999.0;
  }
  time_modified {
    Int32 _ChunkSizes 453;
    Float64 actual_range 1.470171234528697e+9, 1.4786362141052246e+9;
    Float64 colorBarMaximum 120000.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Time";
    String long_name "Time Record Last Modified";
    String short_name "time_mod";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
    Float64 valid_range 0.0, 99999.0;
  }
  longitude {
    String _CoordinateAxisType "Lon";
    Float32 actual_range -75.00555, -75.00555;
    String axis "X";
    Float64 colorBarMaximum 180.0;
    Float64 colorBarMinimum -180.0;
    String ioos_category "Location";
    String long_name "Longitude";
    String standard_name "longitude";
    String units "degrees_east";
  }
  latitude {
    String _CoordinateAxisType "Lat";
    Float32 actual_range 38.26539, 38.26539;
    String axis "Y";
    Float64 colorBarMaximum 90.0;
    Float64 colorBarMinimum -90.0;
    String ioos_category "Location";
    String long_name "Latitude";
    String standard_name "latitude";
    String units "degrees_north";
  }
  depth {
    String _CoordinateAxisType "Height";
    String _CoordinateZisPositive "down";
    Float32 actual_range 0.0, 0.0;
    String axis "Z";
    Float64 colorBarMaximum 8000.0;
    Float64 colorBarMinimum 0.0;
    String colorBarPalette "OceanDepth";
    String ioos_category "Location";
    String long_name "Depth";
    String positive "down";
    String standard_name "depth";
    String units "m";
  }
 }
  NC_GLOBAL {
    Int32 breakout_id 73;
    String buffer_type "waves";
    String cdm_data_type "TimeSeries";
    String cdm_timeseries_variables "station, longitude, latitude";
    String clock_time "Center of period";
    String contact "[email protected],[email protected],[email protected]";
    String Conventions "CF-1.6, COARDS, Unidata Dataset Discovery v1.0";
    String creator_email "[email protected],[email protected],[email protected]";
    String creator_name "Neal Pettigrew";
    String creator_url "http://gyre.umeoce.maine.edu";
    String defaultGraphQuery "time,significant_wave_height&.draw=lines&.color=0x000000";
    Int32 delta_t 30;
    String depth_datum "Sea Level";
    Float64 Easternmost_Easting -75.00555;
    Float64 ending_julian_day_number 57700.82638888889;
    String ending_julian_day_string "2016-11-08 19:50:00";
    String featureType "TimeSeries";
    Float64 geospatial_lat_max 38.26539;
    Float64 geospatial_lat_min 38.26539;
    String geospatial_lat_units "degrees_north";
    Float64 geospatial_lon_max -75.00555;
    Float64 geospatial_lon_min -75.00555;
    String geospatial_lon_units "degrees_east";
    Float64 geospatial_vertical_max 0.0;
    Float64 geospatial_vertical_min 0.0;
    String geospatial_vertical_positive "down";
    String geospatial_vertical_units "m";
    String history
"Tue Aug  2 20:57:05 2016: /usr/local/bin/ncrcat -d time,57602.670138889,57605.670138889 MD205.waves.storm.realtime.nc MD205.waves.storm.realtime.nc.new

2024-12-12T07:06:26Z (local files)
2024-12-12T07:06:26Z http://www.neracoos.org/tabledap/CINAR_DSG_MD205_waves.das";
    String id "MD205";
    String infoUrl "http://www.neracoos.org/";
    String institution "NERACOOS";
    String institution_url "http://gyre.umeoce.maine.edu";
    String julian_day_convention "Julian date convention begins at 00:00:00 UTC on 17 November 1858 AD";
    String keywords "buoy, chemistry, chlorophyll, cinar, circulation, conductivity, created, currents, density, depth, direction, dominant, Earth Science > Oceans > Ocean Chemistry > Chlorophyll, Earth Science > Oceans > Ocean Chemistry > Oxygen, Earth Science > Oceans > Ocean Circulation > Ocean Currents, Earth Science > Oceans > Ocean Optics > Turbidity, Earth Science > Oceans > Ocean Pressure > Sea Level Pressure, Earth Science > Oceans > Ocean Temperature > Water Temperature, Earth Science > Oceans > Ocean Waves > Significant Wave Height, Earth Science > Oceans > Ocean Waves > Wave Period, Earth Science > Oceans > Ocean Winds > Surface Winds, Earth Science > Oceans > Salinity/Density > Conductivity, Earth Science > Oceans > Salinity/Density > Density, Earth Science > Oceans > Salinity/Density > Salinity, height, index, interval, last, level, maine, matching, maximum, mean, mean_wave_direction, mean_wave_direction_qc, microstrain, modified, name, neracoos, nj203, o2, ocean, oceans, offset, offset_time, optics, oxygen, period, pressure, principal, principal_wave_direction, principal_wave_direction_qc, quality, r1_qc, r2_qc, realtime, record, regular, salinity, sea, sea_surface_wave_dominant_period, sea_surface_wave_dominant_period_qc, sea_surface_wave_maximum_height, sea_surface_wave_maximum_height_qc, sea_surface_wave_significant_height, sea_surface_wave_significant_height_qc, seawater, sensor, significant, station, station_name, surface, surface waves, temperature, tempests, time, turbidity, university, water, wave, waves, winds";
    String keywords_vocabulary "GCMD Science Keywords";
    Float64 latitude 38.26539;
    String license
"The data may be used and redistributed for free but is not intended
for legal use, since it may contain inaccuracies. Neither the data
Contributor, ERD, NOAA, nor the United States Government, nor any
of their employees or contractors, makes any warranty, express or
implied, including warranties of merchantability and fitness for a
particular purpose, or assumes any legal liability for the accuracy,
completeness, or usefulness, of this information.";
    String long_name "MD205";
    Float64 longitude -75.00555;
    Float64 magnetic_variation -11.8;
    String Metadata_Conventions "CF-1.6, COARDS, Unidata Dataset Discovery v1.0";
    String mooring_site_id "MD205";
    String mooring_type "Slack";
    String mstrain_manufacturer "University_of_Maine,_PHOG";
    String mstrain_serial_number "UMEMS034";
    String naming_authority "edu.maine";
    Int32 nco_openmp_thread_number 1;
    String neracoos_data_provider "CINAR";
    Float64 Northernmost_Northing 38.26539;
    Int32 number_observations_per_hour 2;
    Int32 number_samples_per_period 2048;
    String original_title "University of Maine MD205 Waves realtime Buoy Sensor";
    String position_datum "WGS 84";
    String processing "realtime";
    String project "NERACOOS";
    String project_url "http://neracoos.org/";
    String publisher "University of Maine";
    String publisher_email "[email protected]";
    String publisher_name "Northeastern Regional Association of Coastal and Ocean Observing Systems (NERACOOS)";
    String publisher_phone "(603) 319 1785";
    String publisher_url "http://www.neracoos.org/";
    String references "http://gyre.umeoce.maine.edu/data/gomoos/buoy/doc/buoy_system_doc/buoy_system/book1.html";
    Int32 sampling_period 20;
    String sampling_period_units "Minutes";
    String short_name "MD205";
    String source "Ocean Data Acquisition Systems (ODAS) Buoy";
    String sourceUrl "(local files)";
    Float64 Southernmost_Northing 38.26539;
    String standard_name_vocabulary "CF-1.6";
    Float64 starting_julian_day_number 57602.70138888889;
    String starting_julian_day_string "2016-08-02 16:50:00";
    String station_name "MD205";
    String station_photo "http://gyre.umeoce.maine.edu/gomoos/images/cinar_buoy.png";
    String station_type "Surface Mooring";
    String subsetVariables "station, longitude, latitude";
    String summary "CINAR Storm MD205 Wave Observations";
    String time_coverage_end "2016-11-08T19:50:00Z";
    String time_coverage_start "2016-08-02T16:50:00Z";
    String time_zone "UTC";
    String title "TEMPESTS MD205 Waves - CINAR";
    Int32 watch_circle_radius 20;
    Float64 water_depth 20.0;
    Float64 Westernmost_Easting -75.00555;
  }
}



Using tabledap to Request Data and Graphs from Tabular Datasets

tabledap lets you request a data subset, a graph, or a map from a tabular dataset (for example, buoy data), via a specially formed URL. tabledap uses the OPeNDAP (external link) Data Access Protocol (DAP) (external link) and its selection constraints (external link).

The URL specifies what you want: the dataset, a description of the graph or the subset of the data, and the file type for the response.

Tabledap request URLs must be in the form
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/datasetID.fileType{?query}
For example,
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/pmelTaoDySst.htmlTable?longitude,latitude,time,station,wmo_platform_code,T_25&time>=2015-05-23T12:00:00Z&time<=2015-05-31T12:00:00Z
Thus, the query is often a comma-separated list of desired variable names, followed by a collection of constraints (e.g., variable<value), each preceded by '&' (which is interpreted as "AND").

For details, see the tabledap Documentation.



ERDDAP, Version 1.82
Disclaimers | Privacy Policy | Contact
