Dataset Title:  E05 Met Buoy Sensor (E05 Meteorology)   RSS
Institution:  Univ. of Maine   (Dataset ID: E05_met_all)
Range: longitude = -69.57349 to -69.56939°E, latitude = 43.83562 to 43.84409°N, depth = -3.0 to -3.0m, time = 2015-08-25T14:50:00Z to 2019-12-17T17:00:00Z
Information:  Summary ? | License ? | FGDC | ISO 19115 | Metadata | Background | Subset | Data Access Form

Graph Type:  ?
X Axis:
Y Axis:
-1 +1

Constraints ? Optional
Constraint #1 ?
Optional
Constraint #2 ?






Server-side Functions ?
 distinct() ?
? (" ")

Graph Settings
Color:
Y Axis Minimum:   Maximum:   Ascending:

(Please be patient. It may take a while to get the data.)

Optional:
Then set the File Type: (File Type information)
and
or view the URL:
(Documentation / Bypass this form ? )
    [The graph you specified. Please be patient.]



Things You Can Do With Your Graphs

Well, you can do anything you want with your graphs, of course. But some things you might not have considered are:

The Dataset Attribute Structure (.das) for this Dataset

Attributes {
 s {
  station {
    String cf_role "timeseries_id";
    String ioos_category "Identifier";
    String long_name "Buoy E05";
  }
  mooring_site_desc {
    String ioos_category "Location";
    String long_name "Station Description";
  }
  water_depth {
    Float32 actual_range 28.0, 90.0;
    String ioos_category "Location";
    String long_name "Water depth at station";
  }
  time {
    Int32 _ChunkSizes 512;
    String _CoordinateAxisType "Time";
    Float64 actual_range 1.4405141999999952e+9, 1.5766020000000134e+9;
    String axis "T";
    String calendar "gregorian";
    String ioos_category "Time";
    String long_name "Time";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
  }
  air_temperature {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.9;
    Float32 actual_range -8.85, 28.6;
    String ancillary_variables "air_temperature_qc";
    Float64 colorBarMaximum 40.0;
    Float64 colorBarMinimum -10.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 20;
    Float32 instrument_range -40.0, 40.0;
    String ioos_category "Temperature";
    Int32 is_dead 0;
    String long_name "Air Temperature";
    String measurement_type "Measured";
    Float64 precision 0.01;
    String short_name "AT";
    String standard_name "air_temperature";
    String units "celsius";
    Float32 valid_range -30.0, 30.0;
  }
  air_temperature_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Air Temperature QC";
    String short_name "ATQC";
    String standard_name "air_temperature data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_gust {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.1;
    Float32 actual_range -7999.0, 43.37;
    String ancillary_variables "wind_gust_qc";
    Float64 colorBarMaximum 30.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 42;
    Float32 instrument_range 0.0, 60.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Gust";
    String measurement_type "Measured";
    Float64 precision 0.001;
    String short_name "WGST";
    String standard_name "wind_speed_of_gust";
    String units "m/s";
    Float32 valid_range 0.0, 50.0;
  }
  wind_gust_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Gust QC";
    String short_name "WGSTQC";
    String standard_name "wind_gust data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_min {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.1;
    Float32 actual_range -7999.0, 25.22;
    String ancillary_variables "wind_min_qc";
    Float64 colorBarMaximum 60.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 42;
    Float32 instrument_range 0.0, 60.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Minimum";
    String measurement_type "Measured";
    Float64 precision 0.001;
    String short_name "WMIN";
    String units "m/s";
    Float32 valid_range 0.0, 50.0;
  }
  wind_min_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Minimum QC";
    String short_name "WMINQC";
    String standard_name "wind_min data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_speed {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.1;
    Float32 actual_range -7999.0, 35.32;
    String ancillary_variables "wind_speed_qc";
    Float64 colorBarMaximum 15.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 401;
    Float32 instrument_range 0.0, 60.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Speed";
    String measurement_type "Measured";
    Float64 precision 0.001;
    String short_name "WSPD";
    String standard_name "wind_speed";
    String units "m/s";
    Float32 valid_range 0.0, 50.0;
  }
  wind_speed_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Speed QC";
    String short_name "WSPDQC";
    String standard_name "wind_speed data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_gust_1s {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.1;
    Float32 actual_range -7999.0, 47.42;
    String ancillary_variables "wind_gust_1s_qc";
    Float64 colorBarMaximum 30.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 42;
    Float32 instrument_range 0.0, 60.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Gust 1 sec";
    String measurement_type "Measured";
    Float64 precision 0.001;
    String short_name "WGST1S";
    String standard_name "wind_speed_of_gust";
    String units "m/s";
    Float32 valid_range 0.0, 50.0;
  }
  wind_gust_1s_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Gust 1s QC";
    String short_name "WGST1SQC";
    String standard_name "wind_gust_1s data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_direction {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 7.5;
    Float32 actual_range 0.0, 359.99;
    String ancillary_variables "wind_direction_qc";
    Float64 colorBarMaximum 360.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String dependency "wind_speed";
    Int32 epic_code 410;
    Float32 instrument_range 0.0, 360.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Direction";
    String measurement_type "Measured";
    Float64 precision 0.1;
    String short_name "WDIR";
    String standard_name "wind_from_direction";
    String units "degrees_true";
    Float32 valid_range 0.0, 360.0;
  }
  wind_direction_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 40;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Direction QC";
    String short_name "WDIRQC";
    String standard_name "wind_from_direction data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  wind_percent_good {
    Int32 _ChunkSizes 1002;
    Float32 _FillValue -999.0;
    Float64 accuracy 0.01;
    Float32 actual_range 0.0, 1.0;
    String ancillary_variables "wind_percent_good_qc";
    Float64 colorBarMaximum 1.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    Int32 epic_code 401;
    Float32 instrument_range 0.0, 1.0;
    String ioos_category "Wind";
    Int32 is_dead 0;
    String long_name "Wind Percent Good";
    String measurement_type "Measured";
    Float64 precision 0.001;
    String short_name "WSPD";
    String standard_name "wind_percent_good";
    String units "1";
    Float32 valid_range 0.0, 1.0;
  }
  wind_percent_good_qc {
    Int32 _ChunkSizes 3506;
    Byte _FillValue -128;
    Byte actual_range 0, 0;
    Float64 colorBarMaximum 128.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String flag_meanings "quality_good out_of_range sensor_nonfunctional questionable";
    Byte flag_values 0, 1, 2, 3;
    String intent "data_quality";
    String ioos_category "Quality";
    String long_name "Wind Percent Good QC";
    String short_name "WPGDQC";
    String standard_name "wind_percent_good data_quality";
    String units "1";
    Byte valid_range -127, 127;
  }
  time_created {
    Int32 _ChunkSizes 501;
    Float64 actual_range 1.4405418569207935e+9, 1.576602663438117e+9;
    Float64 colorBarMaximum 120000.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Time";
    String long_name "Time Record Created";
    String short_name "time_cr";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
    Float64 valid_range 0.0, 99999.0;
  }
  time_modified {
    Int32 _ChunkSizes 501;
    Float64 actual_range 1.4405418569207935e+9, 1.576602663438117e+9;
    Float64 colorBarMaximum 120000.0;
    Float64 colorBarMinimum 0.0;
    String coordinates "time lon lat depth";
    String ioos_category "Time";
    String long_name "Time Record Last Modified";
    String short_name "time_mod";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
    Float64 valid_range 0.0, 99999.0;
  }
  longitude {
    String _CoordinateAxisType "Lon";
    Float32 actual_range -69.57349, -69.56939;
    String axis "X";
    Float64 colorBarMaximum 180.0;
    Float64 colorBarMinimum -180.0;
    String ioos_category "Location";
    String long_name "Longitude";
    String standard_name "longitude";
    String units "degrees_east";
  }
  latitude {
    String _CoordinateAxisType "Lat";
    Float32 actual_range 43.83562, 43.84409;
    String axis "Y";
    Float64 colorBarMaximum 90.0;
    Float64 colorBarMinimum -90.0;
    String ioos_category "Location";
    String long_name "Latitude";
    String standard_name "latitude";
    String units "degrees_north";
  }
  depth {
    String _CoordinateAxisType "Height";
    String _CoordinateZisPositive "down";
    Float32 actual_range -3.0, -3.0;
    String axis "Z";
    Float64 colorBarMaximum 8000.0;
    Float64 colorBarMinimum 0.0;
    String colorBarPalette "OceanDepth";
    String ioos_category "Location";
    String long_name "Depth";
    String positive "down";
    String standard_name "depth";
    String units "m";
  }
 }
  NC_GLOBAL {
    Int32 air_temperature_averaging_period 8;
    String air_temperature_manufacturer "Campbell Scientific, Inc";
    Int32 air_temperature_number_samples_per_observation 60;
    String air_temperature_sensor_model "107";
    String air_temperature_serial_number "CAMAT999";
    String algorithm_ids "WIND_DIR_1.2:  14-Jul-2019 04:46:41";
    String averaging_period_units "Minutes";
    Int32 breakout_id 101;
    String buffer_type "met";
    String cdm_data_type "TimeSeries";
    String cdm_timeseries_variables "station, longitude, latitude";
    String clock_time "Center of period";
    String compass_manufacturer "Cetrek";
    String compass_model "930-580";
    String compass_serial_number "CETCO615512/248";
    String contact "nealp@maine.edu,ljm@umeoce.maine.edu,bfleming@umeoce.maine.edu";
    String control_box_serial_number "UMECB311";
    String Conventions "CF-1.6, COARDS, Unidata Dataset Discovery v1.0";
    String creator_email "nealp@maine.edu,ljm@umeoce.maine.edu,bfleming@umeoce.maine.edu";
    String creator_name "Neal Pettigrew";
    String creator_url "http://gyre.umeoce.maine.edu";
    String defaultGraphQuery "time,air_temperature&time%3E=now-7days&.draw=lines&.color=0x000000";
    Int32 delta_t 10;
    String depth_datum "Sea Level";
    Float64 Easternmost_Easting -69.56939;
    Float64 ending_julian_day_number 58834.70833333349;
    String ending_julian_day_string "2019-12-17 17:00:00";
    String featureType "TimeSeries";
    Float64 geospatial_lat_max 43.84409;
    Float64 geospatial_lat_min 43.83562;
    String geospatial_lat_units "degrees_north";
    Float64 geospatial_lon_max -69.56939;
    Float64 geospatial_lon_min -69.57349;
    String geospatial_lon_units "degrees_east";
    Float64 geospatial_vertical_max -3.0;
    Float64 geospatial_vertical_min -3.0;
    String geospatial_vertical_positive "down";
    String geospatial_vertical_units "m";
    String goes_platform_id "----";
    String history
"2019-07-24 21:26:23:  Modified [lon,lat] to [-69.573411,43.835728].
Wed Jul 24 21:24:57 2019: /usr/local/bin/ncrcat -d time,58688.642361111,58698.642361111 E0503.met.epscor.realtime.nc E0503.met.epscor.realtime.nc.new

2020-06-06T04:26:37Z (local files)
2020-06-06T04:26:37Z http://www.neracoos.org/tabledap/E05_met_all.das";
    String id "E05-met-epscor";
    String infoUrl "http://www.neracoos.org/";
    String institution "Univ. of Maine";
    String institution_url "http://gyre.umeoce.maine.edu";
    String julian_day_convention "Julian date convention begins at 00:00:00 UTC on 17 November 1858 AD";
    String keywords "air, air_temperature, air_temperature data_quality, atmosphere, atmospheric, buoy, chemistry, chlorophyll, circulation, conductivity, created, currents, data, density, department, depth, direction, e05, e0501, Earth Science > Atmosphere > Atmospheric Temperature > Air Temperature, Earth Science > Atmosphere > Atmospheric Temperature > Surface Air Temperature, Earth Science > Atmosphere > Atmospheric Winds > Surface Winds, Earth Science > Oceans > Ocean Chemistry > Chlorophyll, Earth Science > Oceans > Ocean Chemistry > Oxygen, Earth Science > Oceans > Ocean Circulation > Ocean Currents, Earth Science > Oceans > Ocean Optics > Turbidity, Earth Science > Oceans > Ocean Pressure > Sea Level Pressure, Earth Science > Oceans > Ocean Temperature > Water Temperature, Earth Science > Oceans > Ocean Waves > Significant Wave Height, Earth Science > Oceans > Ocean Waves > Wave Period, Earth Science > Oceans > Ocean Winds > Surface Winds, Earth Science > Oceans > Salinity/Density > Conductivity, Earth Science > Oceans > Salinity/Density > Density, Earth Science > Oceans > Salinity/Density > Salinity, good, gust, height, last, level, LOBO, maine, marine, met, meteorology, min, minimum, modified, name, neracoos, o2, ocean, oceanography, oceans, optics, oxygen, percent, period, physical, pressure, quality, realtime, record, salinity, school, sciences, sea, seawater, sec, sensor, significant, speed, station, station_name, surface, temperature, time, turbidity, university, water, wave, waves, wind, wind_from_direction, wind_from_direction data_quality, wind_gust data_quality, wind_gust_1s data_quality, wind_min data_quality, wind_percent_good, wind_percent_good data_quality, wind_speed, wind_speed data_quality, wind_speed_of_gust, winds";
    String keywords_vocabulary "GCMD Science Keywords";
    Float64 latitude 43.83572769165039;
    String license
"The data may be used and redistributed for free but is not intended
for legal use, since it may contain inaccuracies. Neither the data
Contributor, ERD, NOAA, nor the United States Government, nor any
of their employees or contractors, makes any warranty, express or
implied, including warranties of merchantability and fitness for a
particular purpose, or assumes any legal liability for the accuracy,
completeness, or usefulness, of this information.";
    String long_name "E05 near mouth of Damariscotta R Met Epscor";
    Float64 longitude -69.57341130574544;
    Float64 magnetic_variation -15.4;
    String Metadata_Conventions "CF-1.6, COARDS, Unidata Dataset Discovery v1.0";
    String mooring_site_id "E0503";
    String mooring_type "Slack";
    String naming_authority "edu.maine";
    Int32 nco_openmp_thread_number 1;
    String ndbc_site_id "0";
    String neracoos_data_provider "UMO";
    Float64 Northernmost_Northing 43.84409;
    Int32 number_observations_per_hour 6;
    String position_datum "WGS 84";
    String processing "realtime";
    String project "NERACOOS";
    String project_url "http://gyre.umeoce.maine.edu/buoyhome.php";
    String publisher "NERACOOS";
    String publisher_email "info@neracoos.org";
    String publisher_name "Northeastern Regional Association of Coastal and Ocean Observing Systems (NERACOOS)";
    String publisher_phone "(603) 319 1785";
    String publisher_url "http://www.neracoos.org/";
    String references "http://gyre.umeoce.maine.edu/data/gomoos/buoy/doc/buoy_system_doc/buoy_system/book1.html";
    String short_name "E05";
    String source "Ocean Data Acquisition Systems (ODAS) Buoy";
    String sourceUrl "(local files)";
    Float64 Southernmost_Northing 43.83562;
    String standard_name_vocabulary "CF-1.6";
    Float64 starting_julian_day_number 58688.64583333349;
    String starting_julian_day_string "2019-07-24 15:30:00";
    String station_name "E05";
    String station_photo "http://gyre.umeoce.maine.edu/gomoos/images/nmb_buoy.png";
    String station_type "Surface Mooring";
    String subsetVariables "air_temperature_qc,wind_gust_qc,wind_min_qc,wind_speed_qc,wind_gust_1s_qc,wind_direction_qc,wind_percent_good_qc";
    String summary "Ocean observation data from the Northeastern Regional Association of Coastal & Ocean Observing Systems (NERACOOS). The NERACOOS region includes the northeast United States and Canadian Maritime provinces, as part of the United States Integrated Ocean Observing System (IOOS).  These data are served by Unidata's Thematic Realtime Environmental Distributed Data Services (THREDDS) Data Server (TDS) in a variety of interoperable data services and output formats.";
    String time_coverage_end "2019-12-17T17:00:00Z";
    String time_coverage_start "2015-08-25T14:50:00Z";
    String time_zone "UTC";
    String title "E05 Met Buoy Sensor (E05 Meteorology)";
    String uscg_light_list_letter "-";
    String uscg_light_list_number "5297";
    Int32 watch_circle_radius 28;
    Float64 Westernmost_Easting -69.57349;
    Int32 wind_direction_averaging_period 8;
    Int32 wind_direction_number_samples_per_observation 60;
    Float64 wind_gust_averaging_period 0.0833;
    Int32 wind_gust_number_samples_per_observation 5;
    String wind_sensor_manufacturer "Gill_Instruments,_Ltd";
    String wind_sensor_model "WindSonic";
    String wind_sensor_serial_number "GILWM073441";
    Int32 wind_speed_averaging_period 8;
    Int32 wind_speed_number_samples_per_observation 60;
  }
}



Using tabledap to Request Data and Graphs from Tabular Datasets

tabledap lets you request a data subset, a graph, or a map from a tabular dataset (for example, buoy data), via a specially formed URL. tabledap uses the OPeNDAP (external link) Data Access Protocol (DAP) (external link) and its selection constraints (external link).

The URL specifies what you want: the dataset, a description of the graph or the subset of the data, and the file type for the response.

Tabledap request URLs must be in the form
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/datasetID.fileType{?query}
For example,
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/pmelTaoDySst.htmlTable?longitude,latitude,time,station,wmo_platform_code,T_25&time>=2015-05-23T12:00:00Z&time<=2015-05-31T12:00:00Z
Thus, the query is often a comma-separated list of desired variable names, followed by a collection of constraints (e.g., variable<value), each preceded by '&' (which is interpreted as "AND").

For details, see the tabledap Documentation.



ERDDAP, Version 1.82
Disclaimers | Privacy Policy | Contact
